Outdoor Advertising Display
Energy Saving and High Brightness
Energy saving partial voltage power supply, low power consumption, low attenuation, low temperature rise of 20 degrees, energy saving of more than 50%, warranty of more than 2 years, brightness of 5500-10000cd, optional.
Ultra Light and Ultra-thin
The weight of a single module is only 2kg; The size of the standard box is 960 * 960mm. A single standard cabinet is composed of 6 modules. The weight of a single cabinet is only 26kg and the thickness of the cabinet is 75mm. The cabinet can be installed without structure. Compared with the 35kg iron cabinet and the 28.5kg die-casting aluminum cabinet in the early stage, although this display is also die-casting aluminum, the better structural design makes the overall weight of this display lighter and thinner.
The Structure is Simple and the Whole Process is Wireless
Our outdoor advertising display adopts hard connection, wireless in the whole process, simple and neat, and beautiful appearance.
Strong Adaptability to Environment
With ultra-low temperature rise and low attenuation, it can operate normally under the environmental conditions of 80 degrees at most and 40 degrees below zero at least, and can operate normally under the coastal environment for a long time, with strong salt fog resistance.
Flame Retardant and Fireproof
Aluminum module is made of aluminum metal and has a high melting point. Even if the outdoor ambient temperature is high, the LED display screen of aluminum module will not spontaneous combustion, will not deform due to high temperature, and will not become a combustion promoter for other combustibles nearby.
Good Heat Dissipation Effect
The aluminum module has good thermal conductivity, which can quickly dissipate the heat in the screen without installing a fan, and can adapt to worse outdoor environmental conditions.
Safe and Easy to Maintain
Integrated all aluminum design, detachable power cabinet, hard connection, front and rear double maintenance, beautiful and convenient, IP67 high protection, corrosion resistance, high melting point, flame retardant grade greater than V0, high temperature resistance - 40 to 60 ℃.
The energy-saving series die-casting aluminum module LED display adopts reasonable structure, which is easy to realize front and rear maintenance, easy and simple, and saves maintenance time and cost for customers.
High Refresh, High Gray Scale
The ultra-high gray level is more than 16bit, and the ultra-high refresh is more than 3840hz. The display screen is delicate and true, the brightness is stable and uniform, without flicker and graininess.
Driving Scheme
Our outdoor advertising display has the function of blanking above and below the column, high refresh rate, improvement of first row darkness, low gray color deviation and pockmarks.
Large Viewing Angle and High Contrast
3535 lamp beads are adopted, which are composed of red, green and blue chips. The consistency is good, the contrast can reach 5000:1, the viewing angle can reach more than 140 °, high reliability and long service life.
Hot Tags: outdoor advertising display, China, suppliers, manufacturers, customized, wholesale, price, bulk, Light Pole Screen, 3D LED Display, Outdoor Digital Advertising Board, LED Display Screen for Advertising Outdoor
Item | Parameter | Model | |
Module Parameter | Model | SFC57 | SFC10 |
Pixel Composition | 2727 3-in-1 LED | 1R1G1B | |
Pixel Pitch（mm） | 5.7mm | 10mm | |
Module Resolution（W×H） | 84*56=4704dots | 48*32=1536dots | |
Module Size（mm） | 480*320 | 480*320 | |
Module Weight（kg） | 2 | 2 | |
Input Voltage for Module（V） | 3.8 | 4.2 | |
The Max Current for Module（A） | 25 | 25 | |
The Max Power for Module（W） | 95 | ≤131 | |
Cabinet Parameter | Module Qty/Cabinet（W×H） | 2*3 | 2*3 |
Cabinet Resolution（W×H） | 168*168=28224 | 96*96=9216 | |
Cabinet Size（mm） | 960*960 | 960*960 | |
Cabinet Area（m2） | 0.9216 | 0.9216 | |
Cabinet Weight（kg） | 23 | 26 | |
Cabinet Density（dots/m2） | 30625 dots/m² | 10000dots/m² | |
Cabinet Evenness（mm） | ≤0.5 | ≤0.5 | |
Maintenance Method | Front and Rear | Front and Rear | |
Cabinet Material | Die cast aluminum | Die cast aluminum | |
Optical Parameter | Single Dot Brightness Amended | Yes | Yes |
Single Dot Color Amended | Yes | Yes | |
White Balance Brightness（nits） | 5500 | 5500 | |
Color Temperature（K） | 9000-13000, adjustable | 5500-10000, adjustable | |
Visual Angle（Horizontal/Vertical） | 140°/120° | 140°/120° | |
Brightness / Colorful Evenness | ≥99% | ≥99% | |
Contrast Ratio | 5000:1 | 5000:1 | |
Electric Parameter | The Max Power Consumption（W/m²） | 650 | 650 |
Average Power Consumption（W/m²） | 218 | 230 | |
Input Voltage (V) | 200-240 | 200-240 | |
Performance Parameter | Frequency（Hz） | ≥60 | ≥60 |
IC Driving | 1/7 Scanning | 1/2 Scanning | |
Grayscale | It is available within 65536 | ||
Refreshing Ratio（Hz） | 3840 | ||
Color Processor | 12 bit | ||
Lifespan（hrs） | 100,000 H | ||
Work Temperature/Humidity（℃/RH） | -10℃-50℃/10%-98% (Non Condensing) | ||
Storage Temperature/Humidity（℃/RH） | -20℃-60℃/10%-98% (Non Condensing) | ||
